RobStride RobStride 01 Quasi-Direct-Drive Joint Module
Vendor: RobStride
Product: RobStride 01
RobStride 01 quasi-direct-drive joint module integrating driver, motor, planetary reducer and encoder: 17N·m peak / 6N·m rated torque, 7.75:1 ratio, 380g, torque density 44.73N·m/kg, 170W rated output, IP52 (IP67 customizable), with tuning software and dev examples.
| Size | 78.5×78.5×40mm |
| Price | ￥599 |
| Weight | 380g |
| Encoder | ×1 |
| Protection | IP52( IP67) |
| Peak Torque | 17N·m |
| Rated Power | 170W |
| Rated Torque | 6N·m |
| Rated Voltage | 36V (24-48V) |
| Reduction Ratio | 7.75:1 |
