Haydon Kerk Pittman G35A Spur Gearbox (6.3:1-1803.6:1 / 1.236 Nm)

Vendor: Haydon Kerk Pittman / AMETEK (USA)

Product: G35A

Haydon Kerk Pittman (AMETEK, USA) G35A is a Ø35 mm spur gearbox with 11 ratios from 6.3:1 to 1803.6:1 in 1-2 stages; max load 0.706 Nm (100 oz-in) standard, 1.130 Nm (160 oz-in) HT and 1.236 Nm (175 oz-in) WF; only 66.6-92.1 g with gearhead length 24.6-29.6 mm and efficiency 0.48-0.81, pairing with Pittman motors as gearmotors for robot joints, pumps and precision positioning.
