Faulhaber AM2224 Two-Phase PM Stepper Motor (22 mNm, 24 Steps/Rev)
Vendor: Faulhaber (Germany)
Product: AM2224
Faulhaber (Germany) AM2224 is a two-phase 24-steps/rev (15° step angle) permanent-magnet stepper with 22 mNm holding torque (37 mNm boosted) in a Ø22 mm, 43 g package; windings 1.4-12 V / 0.125-1 A per phase, ±10% angular accuracy, -35~70°C, optional preloaded ball bearings and PE22-120 encoder, combinable with 22/2, 22/5 gearheads or 22L linear actuators for precision positioning in optics, medical and robot end-effectors.
| Windings | 1.4-12 V, 0.125-1 A per phase |
| Mass Size | 43 g, Ø22 mm |
| Step Angle | 15 deg (24 steps/rev) |
| Holding Torque | 22 mNm (37 mNm boosted) |
| Operating Temp | -35 ~ 70 C |
| Angular Accuracy | ±10 % |
